GN500-01 FIRE RESISTANCE WIRE

TECNICAL DATA

Condutor: Bare Copper

Temperature range:-60℃~+350℃

Rated Voltage: 500V

O.D.Tolerance: ±0.1mm

Colour:White-Blue-Red-Black-Yellow-Green-Transparent-Yellow/Green

Used for electric heating,petrochemical,electrical and mechanical equipment,power plant,drying pathdrying room,heating source for lighting,electric appliances and other high temperature areas.

GN500-01 FIRE RESISTANCE WIRE

Sectional Area (mm²)	Condutor Construction (mm)	Insulation Thickness (mm)	Outer Diameter (mm）	Max.Condutor Resistance DC20℃ （Ω/km	Packing (m)
0.5	7×0.30	0.5	2.6±0.3	39	200
0.75	11×0.30	0.5	2.7±0.3	26	200
1	14×0.30	0.5	2.8±0.3	19.5	200
1.5	21×0.30	0.5	3.0±0.3	13.3	100
2	28×0.30	0.6	3.3±0.5	10.0	100
2.5	35×0.30	0.6	3.6±0.5	7.98	100
4	56×0.30	0.8	4.7±0.5	4.95	100
6	84×0.30	0.8	5.5±0.5	3.30	100
10	84×0.40	0.8	6.6±0.5	1.91	100
16	228×0.30	0.8	7.8±0.5	1.21	100
16	126×0.40	0.8	7.8±0.5	1.21	100
25	196×0.40	0.8	9.5±0.5	0.78	100
25	361×0.30	0.8	9.5±0.5	0.78	100
35	494×0.30	0.8	11.2±1.0	0.554	100
50	396×0.40	1.2	13.2±1.0	0.386	100
50	703×0.30	1.2	13.2±1.0	0.386	100
70	551×0.40	1.2	15.4±1.0	0.272	100
70	988×0.30	1.2	15.4±1.0	0.272	100
95	760×0.40	1.2	17.4±1.0	0.206	100

GN500-02 FIRE RESISTANCE WIRE

TECNICAL DATA

Condutor: Nickel Copper

Temperature range:-60℃~+500℃

Rated Voltage: 500V

O.D.Tolerance: ±0.1mm

Colour:White-Blue-Red-Black-Yellow-Green-Transparent-Yellow/Green

Used for electric heating,petrochemical,electrical and mechanical equipment,power plant,drying pathdrying room,heating source for lighting,electric appliances and other high temperature areas.

GN500-02 FIRE RESISTANCE WIRE

Sectional Area (mm²)	Condutor Construction (mm)	Insulation Thickness (mm)	Outer Diameter (mm）	Max.Condutor Resistance DC20℃ （Ω/KM	Packing (m)
0.5	7×0.30	0.5	2.6±0.3	40.8	200
0.75	11×0.30	0.5	2.7±0.3	24.3	200
1	14×0.30	0.5	2.8±0.3	20.0	200
1.5	21×0.30	0.5	3.0±0.3	12.6	100
2	28×0.30	0.6	3.3±0.5	9.84	100
2.5	35×0.30	0.6	3.6±0.5	7.37	100
4	56×0.30	0.8	4.7±0.5	4.83	100
6	84×0.30	0.8	5.5±0.5	3.26	100
10	84×0.40	0.8	6.6±0.5	1.80	100
16	228×0.30	0.8	7.8±0.5	1.31	100
16	126×0.40	0.8	7.8±0.5	1.31	100
25	196×0.40	0.8	9.5±0.5	0.758	100
25	361×0.30	0.8	9.5±0.5	0.758	100
35	494×0.30	0.8	11.2±1.0	0.548	100
50	396×0.40	1.2	13.2±1.0	0.384	100
50	703×0.30	1.2	13.2±1.0	0.384	100
70	551×0.40	1.2	15.4±1.0	0.289	100
70	988×0.30	1.2	15.4±1.0	0.289	100
95	760×0.40	1.2	17.4±1.0	0.205	100

GN500-03 FIRE RESISTANCE WIRE 800degree

TECNICAL DATA

Condutor: Nickel

Temperature range:-60℃~+800℃

Rated Voltage: 500V

O.D.Tolerance: ±0.1mm

Colour:White-Blue-Red-Black-Yellow-Green-Transparent-Yellow/Green

Used for electric heating,petrochemical,electrical and mechanical equipment,power plant,drying pathdrying room,heating source for lighting,electric appliances and other high temperature areas.

GN500-03 FIRE RESISTANCE WIRE 800degree

Sectional Area (mm²)	Condutor Construction (mm)	Insulation Thickness (mm)	Outer Diameter (mm）	Max.Condutor Resistance DC20℃ （Ω/km	Packing (m)
0.5	7×0.30	0.5	2.6±0.3	160.4	200
0.75	11×0.30	0.5	2.7±0.3	106.8	200
1	14×0.30	0.5	2.8±0.3	80.0	200
1.5	21×0.30	0.5	3.0±0.3	54.8	100
2	28×0.30	0.6	3.3±0.5	42.0	100
2.5	35×0.30	0.6	3.6±0.5	32.8	100
4	56×0.30	0.8	4.7±0.5	20.4	100
6	84×0.30	0.8	5.5±0.5	13.6	100
10	84×0.40	0.8	6.6±0.5	7.8	100
16	228×0.30	0.8	7.8±0.5	4.96	100
16	126×0.40	0.8	7.8±0.5	4.96	100
25	196×0.40	0.8	9.5±0.5	3.18	100
25	361×0.30	0.8	9.5±0.5	3.18	100
35	494×0.30	0.8	11.2±1.0	2.26	100
50	396×0.40	1.2	13.2±1.0	1.58	100
50	703×0.30	1.2	13.2±1.0	1.58	100
70	551×0.40	1.2	15.4±1.0	1.11	100
70	988×0.30	1.2	15.4±1.0	1.11	100
95	760×0.40	1.2	17.4±1.0	0.84	100
