Flexible Home Appliances Used Silicone Rubber Cable

DETAILS

Nominal Voltage: 300V
Temperature Range: -60 ° C ~+150° C
Testing Voltage: 2000V
Conductor: Bare Copper or Tinned Copper
Insulator: Silicone Rubber
Colours: White-Blue-Red-Black-Brown-Yellow-Green-Transparent-Yellow/Green

Characteristic:
it has excellent high temperature &low temperature resistance, excellent electrical insulation properties, excellent chemical

stability,

high voltage resistance, ageing resistance, long service life.And soft, easy to install.

Application:
Widely used in lighting, household appliances, electric appliances, instrument, electrical and electronic wiring, lamps and

lanterns, burner and high temperature environment.

Flexible Home Appliances Used Silicone Rubber Cable

Silicone Rubber Insulated Wire
AWG	Conductor No./Dia	Overall Diameter (mm)	Insulation Thickness (mm)	Overall Diameter (mm)	Packing Length(metre)
30	7/0.103	0.31	0.76	1.83	610
28	7/0.127	0.38	0.76	1.9	610
26	7/0.160	0.49	0.76	2.01	305
24	7/0.203	0.61	0.76	2.13	305
22	7/0.254	0.76	0.76	2.28	305
20	7/0.310	0.94	0.76	2.47	305
18	7/0.39	1.17	0.76	2.71	305
16	7/0.5	1.5	0.76	3.02	305
