UL 3529 SILICONE WIRE

DETAILS

TECNICAL DATA

Insulation:Silicone Rubber

Condutor:Tinned,Silver or Nickel Copper

Temperature range:-60℃~+150℃

Rated Voltage:600V

O.D.Tolerance: ±0.1mm

Colour:White-Blue-Red-Black-Yellow-Green-Transparent-Yellow/Green

Used for various electric machineries,electronic ceramics,heating parts,car lighting,lighting,ballast etc.

UL 3529 SILICONE WIRE

AWG	Condutor Construction No./mm	Insulation Thickness (mm)	Outer Diameter (mm）	Max. Condutor Resistance DC20℃ （Ω/km）	Packing (m)
12	49×0.30	0.78	4.26	5.64	305
14	40×0.30	0.78	3.46	8.96	305
16	7×0.50	0.78	3.06	14.6	305
17	32×0.20	0.78	2.86	18.3	305
18	7×0.40	0.78	2.76	23.2	305
20	7×0.32	0.78	2.52	36.7	305
22	7×0.26	0.78	2.34	59.4	610
24	7×0.20	0.78	2.16	94.2	610
26	7×0.16	0.78	2.04	150	610
28	7×0.12	0.78	1.92	239	610
30	7×0.10	0.78	1.86	381	610
